Place of Origin: | China |
Brand Name: | MT |
Certification: | CE ISO |
Model Number: | 500*700 |
Minimum Order Quantity: | 1 |
---|---|
Price: | 18USD -25USD |
Packaging Details: | wooden case |
Delivery Time: | 7days |
Payment Terms: | T/T L/C |
Supply Ability: | 10000pcs one year |
Application: | Laser Engraving | Laser Type: | CO2 |
---|
1.Applicable materials
Plexiglas, acrylic, wooden product, plastic, rubber, ceramic tile, crystal, bamboo product, jade, granite, marble, resin and other non-metal materials.
2.Applicable industry
This machine is suitable to professional user for cutting performance in art gift, package, portraits, breast cards, cloth toy and other industries.
3.Technical parameters
Laser power |
50W(optional) |
Laser type |
Hermetic CO2 glass tube |
Power supply |
AC220±10℅50 HZ/AC110±10℅50 HZ |
Working area |
600mmx400mm |
Max moving speed |
1500mm/s |
Locating precision |
<0.01mm |
Min shaping character |
Character:3x3mm,letter:2x2mm |
Operating temperature |
5℃-35℃ |
Resolution ratio |
≦4500dpi |
Control configuration |
DSP |
Data transfer interface |
USB(offline) |
Worktable |
Up and down worktable |
System environment |
WINDOWS 2000/WINDOWS XP |
Cooling way |
Water cooling and protection system |
Graphic format supported |
The file which CorelDraw, Photoshop, AutoCAD can identify(BMP, GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXP,PAT,CDT,CLK,DEX,CSL, CMX,AI,WPG,WMF,EMF,CGM,SVG, SVGZ,PCT,FMV,GEM,CMX) |
Compatible software |
CorelDraw, AutoCAD |
Cutting thickness |
0-10mm(depends on different material) |
Color separation |
Separation of cutting up to 256 colors |
Sloping engraving |
Yes, slope can be designed discretionarily |
Cuts of the water supply the protection |
yes |
Packing |
Plywood case |
Optional parts |
High-grade cooling system imported focus lens double-head cylinder rotary attachment irregular rotary attachment servo motor red dot |
Net weight |
95kg |
Machine dimension |
1200x700x1000(mm) |
