■ Functional Features:
1.PC control type and auto bending,can be used to bend all kinds of aluminum,stainless steel,galvanize plate,iron,brass etc.
2.High precision machining,feeding speed can be 5-20Meter/Min and precision can be 0.05mm.
3. based on the way of the processing material, self-adjusting process parameters, so that it can match with a variety of engraving machines and cutting machine, meet a variety of complex embedded process accuracy as much as possible.
4. The Max. Processed width can be 10-160mm,other ■ Technical Data:
|
Model
|
MT-810
|
|
Control Type
|
LCD control type
|
|
Bending Type
|
Single side bending
|
|
Bending Materials
|
Can bend all kinds of Stainless Steel, Iron, Galvanize Plate, Aluminum etc
|
|
Max. Processed Thickness
|
Aluminum: 0.4-1.2 mm
|
|
Stainless steel: 0.4 -1.0 mm
(or customized up to 0.5-1.5mm for SS)
|
|
Carbon Steel: 0.5 – 1.0 mm
|
|
Mild Steel: 0.5-1.0mm
|
|
Galvanize Plate: 0.5-1.0 mm
|
|
Iron Steel: 0.5-1.0 mm
|
|
Max. Processed Width:
|
15-150mm
|
|
Voltage:
|
AC 220V,50HZ
|
|
Size:
|
1740x760x1450mm
|
|
Weight:
|
400 kgs
|
|
Import File Format
|
PLT
|
|
Export File Format
|
DAT
|
|
Feed speed:
|
5-20 Meter / Min
|
|
Precision
|
0.05mm
|
can be custom-made according to users’ demand.
5. Widely range of applications,can process machining strip and various 0-1.5mm aluminum,galvanized steel,iron sheet etc metal coil.Highly grade molding,the processing of finished products and raw file length deviation less than 0.1mm and can
