Home ProductsAUTO BENDER MACHINE FOR DIE RULE

Auto Bender Machine for die cutting/ auto bender / rule auto bender

Auto Bender Machine for die cutting/ auto bender / rule auto bender

    • Auto Bender Machine for die cutting/ auto bender / rule auto bender
    • Auto Bender Machine for die cutting/ auto bender / rule auto bender
  • Auto Bender Machine for die cutting/ auto bender / rule auto bender

    Product Details:

    Place of Origin: China
    Brand Name: MT
    Certification: ISO
    Model Number: MT510C

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 16500USD
    Packaging Details: wooden case
    Delivery Time: 10days
    Payment Terms: T/T L/C
    Supply Ability: 1000PCS PER YEAR
    Contact Now
    Detailed Product Description

    Auto Bender Machine for die cutting/ auto bender / rule auto bender



    Features and functions:
    1.Process of automatic bending ,lipping  ,cutting ,bridging ,flat cutting and so on functions.
    2.Our machine takes imported steel for bending mould which is tough, high strength, durable
    3.With domestic unique rotary cutting mode and rotary lipping mode , the lip size can be adjusted. Cutter durability can be improved 3-5 times.
    4.Through the gear transmission, high precision and stable
    5.Self-developed updated automatic bending control system with powerful function.
    6.Complete English interface ,easy to learn and easy to understand.
    7.Roller continuous feeding with servo digtal work mode.
    (No need to feed with tool post repeated ,high accuracy and speed)
    8.Control system surport various kinds of file format,such as DXF ,AI,NC and so on.
    9.Applicable to various kinds of process ,such as boxes ,dolls ,cartons ,flowers ,edition.
    10.Approximate bending effect less time for fishing rule equipment ,high work efficient

    ending rule technical parameters





    Maximum angle

    130

    Minimum ARC radius of 180 degree

    R3.0

    Minimum ARC radius of 90 degree

    R1.0

    Minimum bending dimension

    1mm

    Minimum cut size

    0.5mm

    File format Supported

    *AI,*dxf,*NC

    Overall demensions of machine

    1400*640*1500mm

    Computer configuration

    Inter core2 E5300 ,19 inches LCD

    Power Supply

    220v,50hz

    GW

    400kg

    Pressure

    6kg

    Power

    2.2kw









    MT-510C

    Function :Automatic bending ,cutting,lipping ,bridge.

    Height  of rule :7mm-30.0mm

    Thickness  of rule :0.45mm-1.07mm
